ASUS ROG STRIX B850-A GAMING WIFI

Detailní popis produktu

ROG STRIX B850-A Gaming WIFI

* ATX Form Factor

CPU: AMD Socket AM5 for AMD Ryzen™ 9000 & 8000 & 7000 Series Desktop Processors

Chipset: AMD B850 Chipset

Paměť: 4 x DIMM slots, max. 192GB, DDR5

*Podporuje až 8000+MT/s(OC) s procesory Ryzen™ řady 9000 a 8000 a 7000 ECC a Non-ECC, nevyrovnaný modul DIMM

Grafické porty:

1 x DisplayPort

1 x HDMI™ port

Rozšiřující sloty:

AMD Ryzen™ 9000 & 7000 Series Desktop Processors

*1 x PCIe 5.0 x16 slot with Q-Release Slim

AMD Ryzen™ 8000 Series Desktop Processors

*1 x PCIe 5.0 x16 slot with Q-Rlease Slim (supports PCIe 4.0 x8/x4 mode)

AMD B850 Chipset

*1 x PCIe 4.0 x16 slot (supports x4 mode)

Úložný prostor:

Total supports 4 x M.2 slots and 2 x SATA 6Gb/s ports*

AMD Ryzen™ 7000 & 9000 Series Desktop Processors

*M.2_1 (Key M), type 2242/2260/2280 (supports PCIe 5.0x4 mode)

*M.2_2 (Key M), type 2280/22110 (supports PCIe 4.0 x4 mode)

AMD Ryzen™ 8000 Series Desktop Processors

*M.2_1 (Key M), type 2242/2260/2280 (supports PCIe 4.0x4 mode)

*M.2_2 (Key M), type 2280/22110 (supports PCIe 4.0 x4/x2 mode)**

AMD B850 Chipset

*M.2_3 (Key M), type 2280 (supports PCIe 4.0 x4)***

*M.2_4 (Key M), type 2280 (supports PCIe 4.0 x4)

*2 x SATA 6Gb/s ports

Ethernet:

*1 x Intel® 2.5Gb Ethernet

*ASUS LANGuard

Připojení a bluetooth:

*Wi-Fi 7

*2x2 Wi-Fi 7 (802.11be)

*Supports 2.4/5/6GHz frequency band**

*Supports Wi-Fi 7 160MHz bandwidth, up to 2.9Gbps transfer rate.

*Bluetooth® v5.4***

USB:

Zadní USB (Celkově 10 portů)

*1 x USB 20Gbps port (1 x USB Type-C®)

*3 x USB 10Gbps ports (2 x Type-A + 1 x USB Type-C®)

*4 x USB 5Gbps ports (4 x Type-A)

*2 x USB 2.0 ports (4 x Type-A)

Přední USB (Celkově 7 portů)

*1 x USB 10Gbps connector (supports USB Type-C®)

*1 x USB 5Gbps header supports 2 additional USB 5Gbps ports

*2 x USB 2.0 headers support 4 additional USB 2.0 ports

Audio:

ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080

*SupremeFX Shielding Technology

*Savitech SV3H712 AMP

*Rear optical S/PDIF out port

*Premium audio capacitors

*Audio cover

Vstupy/výstupy zadního panelu:

*1 x USB 20Gbps port (1 x USB Type-C®)

*3 x USB 10Gbps ports (2 x Type-A + 1 x USB Type-C®)

*4 x USB 5Gbps ports (4 x Type-A)

*2 x USB 2.0 ports (4 x Type-A)

*1 x DisplayPort

*1 x HDMI™ port

*1 x Wi-Fi module

*1 x Intel® 2.5Gb Ethernet port

*2 x Audio jacks

*1 x Optical S/PDIF out port

*1 x BIOS FlashBack™ button

*1 x Clear CMOS button

Interní vstupy/výstupy:

Ventilátory a chlazení:

*1 x 4-pin CPU Fan header

*1 x 4-pin CPU OPT Fan header

*1 x 4-pin AIO Pump header

*4 x 4-pin Chassis Fan headers

Napájení:

*1 x 24-pin Main Power connector

*2 x 8-pin +12V CPU Power connector

Úložiště:

*4 x M.2 slots (Key M)

*2 x SATA 6Gb/s ports

USB:

*1 x USB 10Gbps connector (supports USB Type-C®)

*1 x USB 5Gbps header supports 2 additional USB 5Gbps ports

*2 x USB 2.0 headers support 4 additional USB 2.0 ports

Různé:

*3 x Addressable Gen 2 headers

*1 x CPU Over voltage jumper

*1 x Front Panel Audio header (F_AUDIO)

*1 x Power button

*1 x 10-1 pin Front System Panel header

*1 x Thermal Sensor header

*1 x Thunderbolt™ (USB4®) header

Příslušenství:

Kabely:

*2 x SATA 6Gb/s cables

Různé:

*1 x ASUS WiFi Q-Antenna

*1 x Cable ties package

*1 x M.2 Q-Latch package

*1 x M.2 Q-Slide package

*1 x ROG key chain

*1 x ROG Strix stickers

*4 x M.2 rubbers

Instalační média:

*1 x USB drive with utilities and drivers

Dokumenty:

*1 x Quick start guide
